Electric e-Winch 250kg
by Gebuwin
SKU e-W250
Capacity: up to 250Kg
Save 35%
Price on application.
Newly developed electric pulling and lifting electric winch with a powerful three-phase motor, budget-friendly and strong in its work.
- Robust and safe electric lifting and pulling winch
- Powerful three-phase motor
- Budget-friendly and strong in its work
| Specification | Value |
|---|---|
| Capacity 1st layer | 250 kg (551 lb) |
| Capacity top layer | 109 (12) kg (240 lb) |
| Rope diameter-Ø | 4 mm (0.16 in) |
| Rope storage 1st layer | 5,7 meter (19 ft) |
| Rope storage top layer | 122 meter (400 ft) |
| Lifting speed | 5,2 m/min (17 ft/min) |
| Motor output (400 V) | 0,37 kW |
| Current (400V) | 1 A |
| FEM classification | 1Bm |
| Min. breaking load rope | 14,7 kN |
| Finish | Standard one layer of paint |
| Weight (without rope) | 52 kg (115 lb) |
| Type name | e-W250 |
This product can lift a maximum of: 250Kg
If you require a different maximum lift capacity, please select from the options below:
Price on application.
If the options here don't meet your requirements, we can customise your order.
Please give us a call on (021) 4885 311 or complete the quote request form.
