Spur gear hand winch 1000kg
Capacity: up to 1000Kg
Beautifully executed spur gear winch, fast and easy. The winch can be mounted to both the wall and the floor. When used for pulling a free spool mechanism is available to disengage the drum. The hand winch is IP54 standardised, which means that it is resistant to water splashes. In addition to its normal version, this winch is also available in stainless steel 304. In short, this is a robust player among hand winches that goes the extra mile when it comes to possibilities and capacity.
- High speed due to spur gear transmission
- Semi-closed housing
- Load pressure brake with double ratchet system
| Capacity 1st layer | 1000 kg (2205 lb) |
|---|---|
| Capacity 4th layer | 726 kg (1601 lb) |
| Capacity top layer | 614 kg (1354 lb) |
| Lifting speed | 1,2 m/min (4 ft/min) |
| Rope diameter-Ø | 8 mm (0.31 in) |
| MBL of cable | 34 kN |
| Rope storage 1st layer | 3,5 meter (11 ft) |
| Rope storage 4th layer | 19,5 meter (64 ft) |
| Rope storage top layer | 33 meter (108 ft) |
| Crank effort at full load | 11 kg (24 lb) |
| Weight (without rope) | 27 kg (60 lb) |
| Article number | 77281600 |
| Type name | TL1000 |
This product can lift a maximum of: 1000Kg
If you require a different maximum lift capacity, please select from the options below:
Price on application.
If the options here don't meet your requirements, we can customise your order.
Please give us a call on (021) 4885 311 or complete the quote request form.
