Spur gear hand winch 1500kg
Capacity: up to 1500Kg
Beautifully executed spur gear winch, fast and easy. The winch can be mounted to both the wall and the floor. When used for pulling a free spool mechanism is available to disengage the drum.
The hand winch is IP54 standardised, which means that it is resistant to water splashes. In addition to its normal version, this winch is also available in stainless steel 304.
In short, this is a robust player among hand winches that goes the extra mile when it comes to possibilities and capacity.
- High speed due to spur gear transmission
- IP54 – resistant to water splashes
- Suitable for wall and floor mounting, with the possibility of free-wheeling and in stainless steel
| Capacity 1st layer | 1500 kg (3307 lb) |
|---|---|
| Capacity 4th layer | 1025 kg (2260 lb) |
| Capacity top layer | 927 kg (2044 lb) |
| Lifting speed | 0,8 m/min (3 ft/min) |
| Rope diameter | 10 mm (0.39 in) |
| MBL of cable | 51 kN |
| Rope storage 1st layer | 2,5 meter (8 ft) |
| Rope storage 4th layer | 15,4 meter (51 ft) |
| Rope storage top layer | 21 meter (69 ft) |
| Crank effort at full load | 12 kg (26 lb) |
| Weight (without rope) | 27,5 kg (61 lb) |
| Article number | 77151100 |
| Type name | TL1500 |
This product can lift a maximum of: 1500Kg
If you require a different maximum lift capacity, please select from the options below:
Price on application.
If the options here don't meet your requirements, we can customise your order.
Please give us a call on (021) 4885 311 or complete the quote request form.
